Property | Value |
---|---|
Crank Shaft Dia | Ø180mm |
Stroke Fixed (Optional) | 150mm |
Adj. Stroke Length (Optional) | 5-150mm |
Hole In Ram (Dia x Depth) | T-Slot Plate |
Hole In Bed | 360mm |
Hole In Bloster | 165mm |
Bed Area (A x B) | 1050x700mm |
Shut Height | 450mm |
S.P.M | 35 |
Center To Back (E) | 320mm |
Distance Between Bed To Ram(D-1) | 600mm |
Floor To Top Of Bed (D-2) | 900mm |
Total (H x L x W) | 3100x1500x1800mm |
Electric Motor | 15HP/1440 |
Weight Net (Approx) | 9250 kg |
